| MODEL | OUTER SIZE | NECK SIZE | CEILING | ACCESSORIES | COLOUR |
|---|---|---|---|---|---|
| ACD2 Two Way | 595×595 | 450×450 | Plain / Tegular | Collar Damper (D) | Powder Coated |
| 450×450 | 375×375 | Anodised | |||
| 375×375 | 300×300 | Wood Finish | |||
| 300×300 | 225×225 | Mill Finish | |||
| 225×225 | 150×150 | Chrome Finish |
Square Ceiling Diffuser - Two Way Throw
ACD2
Diffuser
Sivakasi, Tamil Nadu
A square ceiling diffuser with two-way throw directs airflow in two opposite directions parallel to the ceiling plane
Dual Directional Airflow: This diffuser disperses airflow in two opposite directions parallel to the ceiling plane, providing balanced ventilation or air distribution.
Adjustable Louvers: Typically equipped with adjustable louvers or blades, allowing users to customize the airflow direction according to their preferences or specific room requirements.
Enhanced Air Circulation: By directing airflow both horizontally across the ceiling and downwards into the room, it promotes better air circulation and temperature distribution throughout the space.
Versatile Applications: Suitable for various environments such as offices, conference rooms, and open-plan areas where uniform airflow in multiple directions is needed for optimal comfort.
Improved HVAC Efficiency: The two-way throw design helps optimize the performance of heating, ventilation, and air conditioning (HVAC) systems by ensuring efficient air distribution and reducing energy consumption.
| MODEL | OUTER SIZE | NECK SIZE | CEILING | ACCESSORIES | COLOUR |
|---|---|---|---|---|---|
| ACD2 Two Way | 595×595 | 450×450 | Plain / Tegular | Collar Damper (D) | Powder Coated |
| 450×450 | 375×375 | Anodised | |||
| 375×375 | 300×300 | Wood Finish | |||
| 300×300 | 225×225 | Mill Finish | |||
| 225×225 | 150×150 | Chrome Finish |
Option A: Screw on front side of flange
Option B: Concealed screw on inside surface of frame
Option C: Placement of diffuser directly on the false ceiling frame.
